IP8-BIR4
8MP (4K) ADVANCED IR LED DOME CAMERA
4K UHD (3840x2160) / 1/2.6 inch 10Mega pixel CMOS image sensor
IR LED 06 pcs
Wide Dynamic Range (Digital WDR (ATR-EX)) / Day and Night Mode (Auto, Day, Night External)
Noise Reduction (2D-NR, 3D-NR) / BLC / HLC / LDC / Tamper / Defog / Image Effect
Privacy Mask / Video Motion Detection
ICR V/F lens, DC Auto IRIS V/F Lens, DC Auto IRIS & TDN V/F Lens
2.8-12MM VARIFOCAL LENS
Image Sensor 1/2.6 inch 10Mega pixel CMOS image sensor
Hardware 32bit Embedded CPU GM8139SF, Flash 256Mbytes /SDRAM: 512Mbytes. Linux version 3.3.0 operating system
Video compression H.264, Motion JPEG
Frame rate Primary upto max 15fps @ 4K UHD
Video Streaming Motion JPEG and H.264 Triple Streamming (Simultaneously). Independently Controllable frame rate and bandwidth
Time Stamp Supported ( Date/Time Only) in primary streem
Image setting Compression levels: 6 level, Color: color, black & white
LAN interface 10/100BaseT Ethernet auto sensing
Advanced Service Up to 5.6M memory for Pre/Post alarm buffer E-Mail, FTP, IP notification, Alarm Notification to e-mail, CGI Call by event or schedule
Built-in Motion detections Accuracy: 12x12=144 blocks. Motion Sensitivity : -100 ~ 100 : 100 is hypersensitive
Privacy zone Upto 8 zones
PWR Consumption Max. DC 3.3 Volt max 1200±100 mA, average 840±50 mA
Operating Environment Temperature : 32° ~ 122°F (0° ~ 50°C), Humidity : 20 ~ 80% RH(non-condensing)
Simultaneous clients Live-cast for up to 16 clients
Video access Video access from Web browser
Developer support Provides HTTP CGI API, ActiveX control development kit
System integration support Powerful API for software integration available at http://www.flexwatch.com, including Simple Viewer API, FlexWATCH Control SDK, event trigger data in video stream, embedded scripting and access to serial port peripherals over HTTP/TCP User can be installed user program daemon for event notification or sending image.
Supported protocols HTTP, RTP/RTSP(Uni/Multicast), TCP/IP(v4/v6), UDP, FTP, Telnet, HTTPS, RARP, PPPoE, SNMP, PAP, CHAP, DHCP, NTP, SMTP client, uPnP & etc
