Image Sensor 1/2.6 inch 10Mega pixel CMOS image sensor

Hardware 32bit Embedded CPU GM8139SF, Flash 256Mbytes /SDRAM: 512Mbytes. Linux version 3.3.0 operating system

Video compression H.264, Motion JPEG

Frame rate Primary upto max 15fps @ 4K UHD

Video Streaming Motion JPEG and H.264 Triple Streamming (Simultaneously). Independently Controllable frame rate and bandwidth

Time Stamp Supported ( Date/Time Only) in primary streem

Image setting Compression levels: 6 level, Color: color, black & white

LAN interface 10/100BaseT Ethernet auto sensing

Advanced Service Up to 5.6M memory for Pre/Post alarm buffer E-Mail, FTP, IP notification, Alarm Notification to e-mail, CGI Call by event or schedule

Built-in Motion detections Accuracy: 12x12=144 blocks. Motion Sensitivity : -100 ~ 100 : 100 is hypersensitive

Privacy zone Upto 8 zones

PWR Consumption Max. DC 3.3 Volt max 1200±100 mA, average 840±50 mA

Operating Environment Temperature : 32° ~ 122°F (0° ~ 50°C), Humidity : 20 ~ 80% RH(non-condensing)

Simultaneous clients Live-cast for up to 16 clients

Video access Video access from Web browser

Developer support Provides HTTP CGI API, ActiveX control development kit

System integration support Powerful API for software integration available at http://www.flexwatch.com, including Simple Viewer API, FlexWATCH Control SDK, event trigger data in video stream, embedded scripting and access to serial port peripherals over HTTP/TCP User can be installed user program daemon for event notification or sending image.

Supported protocols HTTP, RTP/RTSP(Uni/Multicast), TCP/IP(v4/v6), UDP, FTP, Telnet, HTTPS, RARP, PPPoE, SNMP, PAP, CHAP, DHCP, NTP, SMTP client, uPnP & etc
